Holtite (Hotswap) Sockets For PCB/Switches - Gold 8134-HC-8P2
€18.00*
€15.13 excl. sales tax
Currently out of stock
Product number:
PP-131_50
Product information "Holtite (Hotswap) Sockets For PCB/Switches - Gold 8134-HC-8P2"
- Turn allmost all PCB into hot-swappable keyboard
- You will need 2 sockets per switch
- Not all PCB are compatible with these sockets! Please read below for an ongoing compatibility list.
What is Hotswap?
You can swap your switches/led easily without desoldering it.
How to install the sockets.
Compatibility List
| PCB | Status | Switches | LEDs | Comments | Verification links | ||
| Socket | Fit | Socket | Fit | ||||
| B.face | Verified | 8134-HC-8P3/2 | Tight | 6-1437514-7/6 | Tight | Not entirely flush (waiting for more responses with different soldering iron tips) | https://www.reddit.com/r/MechanicalKeyboards/comments/5a399o/guide_how_to_make_your_pcb_hotswappable/ |
| B.fake | Verified | 8134-HC-8P3/2 | Loose | 6-1437514-7/6 | Tight | https://www.reddit.com/r/MechanicalKeyboards/comments/558zuj/switch_swappable_jd45/d8g2210/ | |
| Clueboard switch tester | Verified | 8134-HC-8P3/2 | Loose | N/A | N/A | https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9gdy04/ | |
| Drevo Gramr | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Perfect | CAUTION, different reports for different users. | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dak76rw/ |
| https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dd2wndi/ | |||||||
| Duck Black Bird v1.0 | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Tight | LED socket don't sit entirely flush | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dady9mf/ |
| Duck Eagle/Viper v1 | Verified | 8134-HC-8P3/2 | ... | 6-1437514-7/6 | Perfect | No info on the switches but exist ALPS modifications. | Confirmed by /u/E3Eves via PM |
| Ergodox Infinity Kit | Verified | 8134-HC-8P3/2 | Falls through | 6-1437514-7/6 | Don't fit | Switch holes are oval to accommodate for ALPS switches. | https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9grt8d/ |
| FaceW SPRiT PCB | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Perfect | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dcip2em/ | |
| Filco Majestouch 2 | Verified | 8134-HC-8P3/2 | Perfect | N/A | N/A | Confirmed by /u/E3Eves via PM | |
| GH60 | Verified | 8134-HC-8P3/2 | Loose | 6-1437514-7/6 | Don't fit | Some users report switch Holtite will fall through. | https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9gojxa/ |
| GON Nerd60 (LeandreN R4) | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Falls through | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/d9kiluj/ | |
| GSX60RGB | Verified | 8134-HC-8P3/2 | Perfect | N/A | N/A | From Taobao | https://m.reddit.com/r/MechanicalKeyboards/comments/5gq01p/photos_finished_my_hot_swappable_backlit_rgb_60/ |
| ikbc Poker 2 | Verified | ... | 6-1437514-7/6 | Perfect | Still pending for the switches | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/d9j71pw/ | |
| JD40 | Measured | 8134-HC-8P3/2 | ... | 6-1437514-7/6 | ... | Same as JD45 | |
| JD45 | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Falls through | LED sockets fall through. You can try this at your own risk. | https://www.reddit.com/r/MechanicalKeyboards/comments/5a399o/guide_how_to_make_your_pcb_hotswappable/d9djohy/ |
| KBD75 R1 (Black PCB) | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Perfect | You can have issues with the |\ key because it's only a half hole. | Confirmed by tobsn |
| KBDFans KBD67 Rev2 | Verified | 8134-HC-8P3/2 | Confirmed by Telegnom | ||||
| KC60 | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Don't fit | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dcp1zih/ | |
| Kwark 1.1 | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Tight | https://m.reddit.com/r/MechanicalKeyboards/comments/5cza9y/kwark_11_pcb_holtite_compatible_holes/ | |
| Leeku Alphas L3 | Verified | 6-1437514-7/6 | Perfect | No info on the switches but exist ALPS modifications. | Confirmed by /u/E3Eves via PM | ||
| Leeku L3 TKL | Verified | 8134-HC-8P3/2 | Perfect | Perfect fit for everything but the bottom row which uses a smaller hole in some places | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dc45z0n/ | ||
| Leeku MXAlps 3000 PCB | Verified | 6-1437514-7/6 | Perfect | No info on the switches but exist ALPS modifications. | Confirmed by /u/E3Eves via PM | ||
| Let's Split PCB | Verified | 8134-HC-8P3/2 | Falls through | N/A | N/A | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/db8wwn1/ | |
| M10-A | Verified | 8134-HC-8P3/2 | Falls through | 6-1437514-7/6 | Falls through | Confirmed by /u/japanitrat | |
| MechanicalEagle-Z77 | Verified | 8134-HC-12P3/2 | Don't fit | Socket will go in, but keypres is not registered | Confirmed by /u/Metalbolt0 via PM | ||
| Minivan (MX) | Measured | 8134-HC-8P3/2 | ... | 6-1437514-7/6 | ... | Should work (/u/evangs confirmed). Waiting for verified build | https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9gxonv/ |
| Octagon v2 | Measured | 8134-HC-8P3/2 | Don't fit | 6-1437514-7/6 | Don't fit | https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9hsk2p/ | |
| Planck | Verified | 8134-HC-8P3/2 | Perfect | LEDs not tried | https://m.reddit.com/r/olkb/comments/5aj4yf/comment/d9l8ojk | ||
| Preonic rev 1 | Verified | 8134-HC-8P3/2 | Loose | 6-1437514-7/6 | Loose | could use some soldering | https://www.reddit.com/r/olkb/comments/8lv31q/led_holtite_8134hc5p2_test_on_preonic_rev_1_pcb/ |
| PS2AVRGB | Verified | 8134-HC-8P3/2 | Falls through | Confirmed by /u/mattno5ss via PM | |||
| Quickfire Rapid/Stealth PCBv 2.2 | Verified | 8134-HC-8P3/2 | Don't fit | Confirmed by /u/Metalbolt0 via PM | |||
| RS78 | Verified | 8134-HC-8P3/2 | Falls through | 6-1437514-7/6 | ... | No info on the LEDs | https://www.reddit.com/r/MechanicalKeyboards/comments/5a399o/guide_how_to_make_your_pcb_hotswappable/d9dp13n/ |
| RS96 | Measured | 8134-HC-8P3/2 | Don't fit | N/A | N/A | ||
| RSII+ ver.C | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Tight | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dbzid8w/ | |
| S60-X | Measured | 8134-HC-8P3/2 | ... | 6-1437514-7/6 | ... | Should work. Waiting for verified build | |
| Sentraq S60RGB | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Perfect | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dd2wndi/ | |
| https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dco1fn1/ | |||||||
| TXPad PCB | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Perfect | https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dc45z0n/ | |
| VE.A | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Tight | https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9gahj1/ | |
| XD60 (Xiudi) | Verified | 8134-HC-8P3/2 | Loose | 6-1437514-7/6 | Don't fit | Fitting seems to vary (between perfect and loose). LEDs not fitting reported by /u/The_Gout | https://www.reddit.com/r/MechanicalKeyboards/comments/5jeatu/xd60_hotswapable/ |
| Zeal60 | Verified | 8134-HC-8P3/2 | Perfect | N/A | N/A | Flimsy halfpad at \| key, be careful. No LEDs since it comes with RGB preinstalled) | Confirmed by /u/japanitrat |
| QMK 65 A | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | ... | LEDs not tried | Confirmed by /u/japanitrat |
| DZ60 | Verified | 8134-HC-8P3/2 | Loose | 6-1437514-7/6 | inconsistent holes sizes. loose fit or falling through. Requires soldering | https://www.reddit.com/r/MechanicalKeyboards/comments/78linw/dz60_holtite_compatibility/ | |
| POK3R | Verified | 8134-HC-8P3/2 | Perfect | 6-1437514-7/6 | Perfect | after desoldering | https://www.reddit.com/r/MechanicalKeyboards/comments/5uqltx/hot_swappified_my_pok3r/ |
| ALF X2 | 8134-HC-8P3/2 | Loose | requires some soldering | Confirmed /u/japanitrat | |||
