Mill-Max 0305 Holtite for Switches - Hotswap Sockets

Compatible with Cherry MX switches and clones Compatible with Kailh Hotswap socket footprint Gold plated contacts Sold in packs of 10 (Quantity 1 = 10 sockets) Require a compatible PCB Technical specification: Rating voltage range: 2A AC to 12V AC/DC Rating current: 10μA DC to 10mA AC/DC Contact resistance: 200mΩ (maximum) Insulation resistance: 100mΩ (minimum) (100V DC) Withstand Voltage: AC100V(50-60Hz) Motion Force: 3.0kgf max Operating Life: 100 Cycles (can replace switches 100 times)

Turn allmost all PCB into hot-swappable keyboard You will need 2 sockets per switch  Not all PCB are compatible with these sockets! Please read below for an ongoing compatibility list.   What is Hotswap?You can swap your switches/led easily without desoldering it.   How to install the sockets.   Compatibility List  PCB Status Switches LEDs Comments Verification links     Socket Fit Socket Fit     B.face Verified 8134-HC-8P3/2 Tight 6-1437514-7/6 Tight Not entirely flush (waiting for more responses with different   soldering iron tips) https://www.reddit.com/r/MechanicalKeyboards/comments/5a399o/guide_how_to_make_your_pcb_hotswappable/ B.fake Verified 8134-HC-8P3/2 Loose 6-1437514-7/6 Tight   https://www.reddit.com/r/MechanicalKeyboards/comments/558zuj/switch_swappable_jd45/d8g2210/ Clueboard switch tester Verified 8134-HC-8P3/2 Loose N/A N/A   https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9gdy04/ Drevo Gramr Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Perfect CAUTION, different reports for different users. https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dak76rw/ https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dd2wndi/ Duck Black Bird v1.0 Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Tight LED socket don't sit entirely flush https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dady9mf/ Duck Eagle/Viper v1 Verified 8134-HC-8P3/2 ... 6-1437514-7/6 Perfect No info on the switches but exist ALPS modifications. Confirmed by /u/E3Eves via PM Ergodox Infinity Kit Verified 8134-HC-8P3/2 Falls through 6-1437514-7/6 Don't fit Switch holes are oval to accommodate for ALPS switches. https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9grt8d/ FaceW SPRiT PCB Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Perfect   https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dcip2em/ Filco Majestouch 2 Verified 8134-HC-8P3/2 Perfect N/A N/A   Confirmed by /u/E3Eves via PM GH60 Verified 8134-HC-8P3/2 Loose 6-1437514-7/6 Don't fit Some users report switch Holtite will fall through. https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9gojxa/ GON Nerd60 (LeandreN R4) Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Falls through   https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/d9kiluj/ GSX60RGB Verified 8134-HC-8P3/2 Perfect N/A N/A From Taobao https://m.reddit.com/r/MechanicalKeyboards/comments/5gq01p/photos_finished_my_hot_swappable_backlit_rgb_60/ ikbc Poker 2 Verified   ... 6-1437514-7/6 Perfect Still pending for the switches https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/d9j71pw/ JD40 Measured 8134-HC-8P3/2 ... 6-1437514-7/6 ... Same as JD45   JD45 Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Falls through LED sockets fall through. You can try this at your own   risk. https://www.reddit.com/r/MechanicalKeyboards/comments/5a399o/guide_how_to_make_your_pcb_hotswappable/d9djohy/ KBD75 R1 (Black PCB) Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Perfect You can have issues with the |\ key because it's only a half   hole. Confirmed by tobsn KBDFans KBD67 Rev2 Verified 8134-HC-8P3/2         Confirmed by Telegnom KC60 Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Don't fit   https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dcp1zih/ Kwark 1.1 Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Tight   https://m.reddit.com/r/MechanicalKeyboards/comments/5cza9y/kwark_11_pcb_holtite_compatible_holes/ Leeku Alphas L3 Verified     6-1437514-7/6 Perfect No info on the switches but exist ALPS modifications. Confirmed by /u/E3Eves via PM Leeku L3 TKL Verified 8134-HC-8P3/2 Perfect     Perfect fit for everything but the bottom row which uses a   smaller hole in some places https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dc45z0n/ Leeku MXAlps 3000 PCB Verified     6-1437514-7/6 Perfect No info on the switches but exist ALPS modifications. Confirmed by /u/E3Eves via PM Let's Split PCB Verified 8134-HC-8P3/2 Falls through N/A N/A   https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/db8wwn1/ M10-A Verified 8134-HC-8P3/2 Falls through 6-1437514-7/6 Falls through   Confirmed by /u/japanitrat MechanicalEagle-Z77 Verified 8134-HC-12P3/2 Don't fit     Socket will go in, but keypres is not registered Confirmed by /u/Metalbolt0 via PM Minivan (MX) Measured 8134-HC-8P3/2 ... 6-1437514-7/6 ... Should work (/u/evangs confirmed). Waiting for verified build https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9gxonv/ Octagon v2 Measured 8134-HC-8P3/2 Don't fit 6-1437514-7/6 Don't fit   https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9hsk2p/ Planck Verified 8134-HC-8P3/2 Perfect     LEDs not tried https://m.reddit.com/r/olkb/comments/5aj4yf/comment/d9l8ojk Preonic rev 1 Verified 8134-HC-8P3/2 Loose 6-1437514-7/6 Loose could use some soldering https://www.reddit.com/r/olkb/comments/8lv31q/led_holtite_8134hc5p2_test_on_preonic_rev_1_pcb/ PS2AVRGB Verified 8134-HC-8P3/2 Falls through       Confirmed by /u/mattno5ss via PM Quickfire Rapid/Stealth PCBv   2.2 Verified 8134-HC-8P3/2 Don't fit       Confirmed by /u/Metalbolt0 via PM RS78 Verified 8134-HC-8P3/2 Falls through 6-1437514-7/6 ... No info on the LEDs https://www.reddit.com/r/MechanicalKeyboards/comments/5a399o/guide_how_to_make_your_pcb_hotswappable/d9dp13n/ RS96 Measured 8134-HC-8P3/2 Don't fit N/A N/A     RSII+ ver.C Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Tight   https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dbzid8w/ S60-X Measured 8134-HC-8P3/2 ... 6-1437514-7/6 ... Should work. Waiting for verified build   Sentraq S60RGB Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Perfect   https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dd2wndi/ https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dco1fn1/ TXPad PCB Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Perfect   https://www.reddit.com/r/MechanicalKeyboards/comments/5amslt/guidehotswap_compatibility_table/dc45z0n/ VE.A Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Tight   https://www.reddit.com/r/MechanicalKeyboards/comments/5aghci/buying_group_buy_for_hot_swap_connectors/d9gahj1/ XD60 (Xiudi) Verified 8134-HC-8P3/2 Loose 6-1437514-7/6 Don't fit Fitting seems to vary (between perfect and loose). LEDs not   fitting reported by /u/The_Gout https://www.reddit.com/r/MechanicalKeyboards/comments/5jeatu/xd60_hotswapable/ Zeal60 Verified 8134-HC-8P3/2 Perfect N/A N/A Flimsy halfpad at \| key, be careful. No LEDs since it comes   with RGB preinstalled) Confirmed by /u/japanitrat QMK 65 A Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 ... LEDs not tried Confirmed by /u/japanitrat DZ60 Verified 8134-HC-8P3/2 Loose 6-1437514-7/6   inconsistent holes sizes. loose fit or falling through.   Requires soldering https://www.reddit.com/r/MechanicalKeyboards/comments/78linw/dz60_holtite_compatibility/ POK3R Verified 8134-HC-8P3/2 Perfect 6-1437514-7/6 Perfect after desoldering https://www.reddit.com/r/MechanicalKeyboards/comments/5uqltx/hot_swappified_my_pok3r/ ALF X2   8134-HC-8P3/2 Loose     requires some soldering Confirmed /u/japanitrat
