Raspberry Pi Pico RP2040 ARM (Board Only)

RP2040 microcontroller 16MB memory (W25Q32) USB-C WS2812 RGB LED (GPIO23) Boot, reset and user button Power LED, User LED (GPIO25) Pin VIN is different from the RaspberryPi Pico (VCC on Pico) Not compatible with Piantor PCB/Kit Flash firmware: Connect the board with a USB cable Press and hold the BOOT button Press and release RST button Release BOOT button A USB mass storage device with the name RPI-RP2 should apprear Drag and drop you firmware file (UF2)

Following the hugely popular Raspberry Pi Pico, the new Raspberry Pi Pico W is a wireless-enabled version of the RP2040-based board, adding 2.4GHz 802.11n WiFi connectivity!At the heart of the Pico W is the RP2040 – the same chip used in the original Raspberry Pi Pico, featuring two ARM Cortex-M0+ cores clocked at 133MHz; 256KB RAM; 30 GPIO pins; and a broad range of interfacing options. This is paired with 2MB of onboard QSPI Flash memory for code and data storage.WiFi is enabled via the use of an Infineon CYW43439 wireless chip. The CYW43439 supports IEEE 802.11 b/g/n wireless LAN, and Bluetooth 5.2; however only wireless LAN is software-supported at launch.With the same footprint and same RP2040 chip, this WiFi Pico can be used as a drop-in replacement for your existing Raspberry Pi Pico projects, upgrading them with WiFi. This is the unsoldered version. It comes without header pins so you'll need to pick some up separately if you're planning on plugging your Pico into into a breadboard or one of our Raspberry Pi Pico add-ons. Documentation  Raspberry Pi Pico W Specifications The main chip on board is the RP2040 made by Raspberry Pi (their first in-house microcontroller chip!) and is a dual-core ARM Cortex M0+ processor, with a flexible clock running up to 133MHz. WiFi is enabled via the use of an Infineon CYW43439. RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz 264kB of SRAM, and 2MB of onboard Flash memory Infineon CYW43439 wireless chip IEEE 802.11n wireless LAN Bluetooth 5.2 (not software supported at launch) WPA3 SoftAP (up to 4 clients) Onboard antenna licenced from ABRACON (connected via SPI to the RP2040) Castellated module allows soldering directly to carrier boards USB 1.1 Host and Device support Low-power sleep and dormant modes Drag & drop programming using mass storage over USB 26 multi-function GPIO pins 2×SPI, 2×I2C, 2×UART, 3×12-bit ADC, 16×controllable PWM channels Real-time clock (RTC) Temperature sensor Accelerated floating-point libraries on-chip 8×Programmable IO (PIO) state machines for custom peripheral support Dimensions (WxLxH): 21mm x 51.3mm x 3.9mm Weight: 4g

Following the hugely popular Raspberry Pi Pico, the new Raspberry Pi Pico W is a wireless-enabled version of the RP2040-based board, adding 2.4GHz 802.11n WiFi connectivity!At the heart of the Pico W is the RP2040 – the same chip used in the original Raspberry Pi Pico, featuring two ARM Cortex-M0+ cores clocked at 133MHz; 256KB RAM; 30 GPIO pins; and a broad range of interfacing options. This is paired with 2MB of onboard QSPI Flash memory for code and data storage.WiFi is enabled via the use of an Infineon CYW43439 wireless chip. The CYW43439 supports IEEE 802.11 b/g/n wireless LAN, and Bluetooth 5.2; however only wireless LAN is software-supported at launch.With the same footprint and same RP2040 chip, this WiFi Pico can be used as a drop-in replacement for your existing Raspberry Pi Pico projects, upgrading them with WiFi. This is the unsoldered version. It comes without header pins so you'll need to pick some up separately if you're planning on plugging your Pico into into a breadboard or one of our Raspberry Pi Pico add-ons. Documentation  Raspberry Pi Pico W Specifications The main chip on board is the RP2040 made by Raspberry Pi (their first in-house microcontroller chip!) and is a dual-core ARM Cortex M0+ processor, with a flexible clock running up to 133MHz. WiFi is enabled via the use of an Infineon CYW43439. RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz 264kB of SRAM, and 2MB of onboard Flash memory Infineon CYW43439 wireless chip IEEE 802.11n wireless LAN Bluetooth 5.2 (not software supported at launch) WPA3 SoftAP (up to 4 clients) Onboard antenna licenced from ABRACON (connected via SPI to the RP2040) Castellated module allows soldering directly to carrier boards USB 1.1 Host and Device support Low-power sleep and dormant modes Drag & drop programming using mass storage over USB 26 multi-function GPIO pins 2×SPI, 2×I2C, 2×UART, 3×12-bit ADC, 16×controllable PWM channels Real-time clock (RTC) Temperature sensor Accelerated floating-point libraries on-chip 8×Programmable IO (PIO) state machines for custom peripheral support Dimensions (WxLxH): 21mm x 51.3mm x 3.9mm Weight: 4g

A low cost, high-performance microcontroller board built around Raspberry Pi's very own chip - the RP2040. Raspberry Pi Pico is Raspberry Pi's first microcontroller board, designed especially for physical computing. Microcontrollers are a different type of device than Single Board Computers (like the Raspberry Pi Zero and previous generations of Pi), they don't run an operating system and they are typically programmed to do just one task - though that task can be pretty intricate and exciting! They're perfect for experimenting with hardware and using as the brains of custom devices, machines and inventions. It can be easily reprogrammed over USB from a Raspberry Pi or other computer using the C/C++ SDK or the official MicroPython port. The landing page is the best place to get started, or scroll down for links to the technical documentation for both the Raspberry Pi Pico microcontroller board and the RP2040 microcontroller chip. This is the unsoldered version. It comes without header pins so you'll need to pick some up separately if you're planning on plugging your Pico into into a breadboard or one of our Raspberry Pi Pico add-ons.   Board Specifications Raspberry Pi Pico is a low-cost, high-performance microcontroller board with flexible digital interfaces, built on silicon designed at Raspberry Pi. Key features include: RP2040 microcontroller chip designed by Raspberry Pi in the United Kingdom Dual-core ARM Cortex M0+ processor, flexible clock running up to 133 MHz 264kB of SRAM, and 2MB of on-board Flash memory Castellated module allows soldering direct to carrier boards USB 1.1 Host and Device support Low-power sleep and dormant modes Drag & drop programming using mass storage over USB 26 multi-function GPIO pins 2×SPI, 2×I2C, 2×UART, 3×12-bit ADC, 16×controllable PWM channels Accurate clock and timer on-chip Temperature sensor Accelerated floating point libraries on-chip 8×Programmable IO (PIO) state machines for custom peripheral support Documentation Documentation for the Raspberry Pi Pico board and the RP2040 microcontroller: Raspberry Pi Pico Datasheet - An RP2040-based microcontroller board RP2040 Datasheet - A microcontroller by Raspberry Pi Hardware design with the RP2040 - Using the RP2040 microcontroller to build boards and products Getting Started with Raspberry Pi Pico - C/C++ development with the Pico and other RP2040-based microcontroller boards Pico C/C++ SDK - Libraries and tools for C/C++ development on the RP2040 microcontroller Pico Python SDK - A MicroPython environment for the RP2040 microcontroller The API level Doxygen documentation for the Raspberry Pi Pico C/C++ SDK is available as a micro-site. Handwiring Keyboards with Pi Pico: 3x3 Macro Pad

RP2040 microcontroller 16MB memory (W25Q32) USB-C WS2812 RGB LED (GPIO23) Boot, reset and user button Power LED, User LED (GPIO25) Pin VIN is different from the RaspberryPi Pico (VCC on Pico) Not compatible with Piantor PCB/Kit Flash firmware: Connect the board with a USB cable Press and hold the BOOT button Press and release RST button Release BOOT button A USB mass storage device with the name RPI-RP2 should apprear Drag and drop you firmware file (UF2)
